As organizations scale their AI infrastructure to support trillion-parameter models, they face a difficult trade-off: reduced training time with lower cost or faster training time with a higher cost. When they checkpoint frequently to speed up recovery time and minimize lost training time, they incur in substantially higher storage cost. And when they checkpoint infrequently, they reduce costs at the risk of losing valuable training progress when failures occur.
This challenge is exacerbated in large distributed training environments, with thousands of accelerators, where issues can occur frequently. According to an article released by Meta, one failure happened every 3 hours during the Meta Llama 3 model training. The GPU issues accounted for 60% of the total failures, and network, CPU, and disks account the other 40%. With infrequent checkpointing, these accumulated failures can result in losing days of training progress over the course of a complete training run, thereby driving up costs and time to market. Frequent checkpoints can saturate networks, overload storage, and result in unpredictable performance.
To help solve these challenges, AWS announced managed tiered checkpointing in Amazon SageMaker HyperPod, a purpose-built infrastructure to scale and accelerate generative AI model development across thousands of AI accelerators. Managed tiered checkpointing uses CPU memory for high-performance checkpoint storage with automatic data replication across adjacent compute nodes for enhanced reliability. Although SageMaker HyperPod identifies node issues automatically and replaces those nodes so your training can resume, managed tiered checkpointing helps you implement the best checkpointing strategy and maximize your training throughput.
Managed tiered checkpointing has been tested on large distributed training clusters ranging from hundreds of GPU to over 15,000 GPU, with checkpoints being saved within seconds.
In this post, we dive deep into those concepts and understand how to use the managed tiered checkpointing feature.
Solution overview
Checkpointing is the method of saving an intermediate model’s state during the training process. You can resume training from a recent checkpoint in the event of an issue by saving the model’s parameters, optimizer states, and other metadata during training. Additionally, you can resolve training problems, such as irregular learning rates, without a full restart by loading an earlier checkpoint state.
Use the following formula to find a rough initial estimate of the total size of the checkpoint for your model without the optimizer state:Model checkpoint size (GB) = (Number of parameters × Bytes per parameter) ÷ 10243 bytesFor example, if you train a Meta Llama 3 70-billion-parameter model using BFloat16 as the parameter’s precision, the checkpoint size will be 130 GB. If you train a DeepSeek-R1 671-billion-parameter model using BFloat16, the checkpoint size will be 1.25 TB. All without storing optimizer states.Checkpoints include optimizer states, training metadata (such as step number), and other additional data, resulting in a larger than expected size. When using an Adam optimizer, the optimizer will save three additional float16 statistics per parameter, resulting in an additional 6 bytes per parameter. Therefore, with the optimizer state saved, the Meta Llama 3 70B model checkpoint size will be approximately 521 GB, and the DeepSeek-R1 671B model checkpoint size will be approximately 5 TB. That is a four-times increase in size, and handling those checkpoints becomes a challenge.
The following table summarizes the checkpoint sizes for each model.
Model name
Size of Checkpoint
Size of Checkpoint + Optimizer States
Meta Llama 3 70B
130 GB
521 GB
DeepSeek R1 671B
1.43 TB
5 TB
It’s also important to consider the training strategy. In a Fully Sharded Data Parallel (FSDP) scenario, each rank (a single GPU process in a distributed training) saves its own part of the checkpoint. At the same time, it reduces the amount of data each rank has to save during a checkpoint, and imposes a stress on the file system level. On a Network File System (NFS) shared file system, those concurrent writes become a bottleneck. Using a distributed file system, such Amazon FSx for Lustre, can help alleviate that pressure at a higher total cost. In a Distributed Data Parallel (DDP) scenario, a single rank writes the complete checkpoint at one time, and all ranks read the checkpoint when loading it back. On the file system level, this means a single writer and multiple readers. On an NFS file system, many readers can be a problem because they will be constrained based on the file system, network stack, and queue size. A single writer, over the network, will not take advantage of all the network throughput. Here again, a fast, distributed file system like FSx for Lustre can help solve those problems at a higher total cost of ownership.
As we can see, traditional checkpointing methods that rely solely on remote persistent storage create a computational overhead during checkpoint creation, because writing terabytes of model parameters to persistent storage might throttle it, consume expensive network bandwidth, and require complex orchestration across distributed systems. By storing checkpoints in fast-access in-memory locations, such as CPU RAM, while maintaining configurable backup to Amazon Simple Storage Service (Amazon S3) for persistence, the system delivers faster recovery times, and is a cost-effective solution compared to traditional disk-based approaches.
Managed tiered checkpointing works as follows:
When training your model, you define the checkpoint frequency.
Model training uses GPU HBM memory to store the model, its parameters, and intermediate results, and do the heavy computation.
Triggering a checkpoint stops model training. The GPU will convert the model weights (tensors) into a state dictionary and copy the data to the instance’s CPU, then the training resumes while managed tiered checkpointing copies the data to RAM.
Because RAM is volatile, managed tiered checkpointing copies the data asynchronously from the host RAM to adjacent nodes using RDMA over Elastic Fabric Adapter (EFA). If a node experiences an issue, its checkpoint data will be available on other nodes too.
From time to time, it copies the data to a second layer of persistent storage, such as Amazon S3. This helps both when writing to RAM fails and when you want to persistently store the checkpoint data for future use.
With managed tiered checkpointing, you can configure frequency and retention policies for both in-memory and persistent storage tiers. You use the first layer (in-memory) to save checkpoints at a high frequency and for fast recovery, periodically saving to Amazon S3 for backup. Managed tiered checkpointing provides a file system that can be seamlessly integrated with your PyTorch Distributed Checkpointing (DCP) training. Adding it to your training script only requires a few lines of code. Furthermore, it improves the performance of checkpoints by using in-memory storage while using other tiers for persistent storage. PyTorch DCP solves the issue of saving a model’s checkpoint when it uses distributed resources, such as multiple GPUs across multiple compute nodes. Trainers, parameters, and the dataset are partitioned across those nodes and resources, then PyTorch DCP saves and loads from multiple ranks in parallel. PyTorch DCP produces multiple files per checkpoint, at least one per rank. Depending on the volume of those files, number and size, shared and network file systems such as NFS will struggle with inode and metadata management. Managed tiered checkpointing helps solve that issue by making it possible to use multiple tiers, reducing intrusion to the training time and still receiving the benefits of PyTorch DCP, such as deduplication of checkpoint data.
With managed tiered checkpointing in SageMaker HyperPod, you can maintain a high training throughput even in large-scale environments prone to failures. It uses your existing SageMaker HyperPod cluster orchestrated by Amazon Elastic Kubernetes Service (Amazon EKS) and compute nodes, and there are no additional costs to use the library.
In the following sections, we explore how to configure the SageMaker HyperPod cluster’s training scripts to use this new feature.
Configure your SageMaker HyperPod cluster for managed tiered checkpointing
SageMaker HyperPod provisions resilient clusters for running machine learning (ML) workloads and developing state-of-the-art models such as large language models (LLMs), diffusion models, and foundation models (FMs). By reducing the complex work of building and maintaining compute clusters using accelerators like AWS Trainium and NVIDIA H200/B200 GPUs, it speeds up the creation of foundation models. To create a new SageMaker HyperPod cluster, refer to the Amazon SageMaker HyperPod Developer Guide. If you want to accelerate your deployment by using field hardened assets, refer to the following GitHub repo.
The examples shared in this post are intended to help you learn more about this new feature. If you’re considering running the examples provided here in a production environment, have your security team review the content and make sure they adhere to your security standards. At AWS, security is the top priority and we understand that every customer has their own security framework.Before creating or updating a cluster to add the managed tiered checkpointing feature, you must set up the EKS pods to access an S3 bucket either on your own account or across accounts. When working with buckets on the same account as the SageMaker HyperPod EKS cluster, you can use the following policy (change your bucket name before applying it):
If the bucket is in a different account, you must authorize an AWS Identity and Access Management (IAM) principal to access those buckets. The following IAM policy will do that for you. Be sure to change both the bucket name and the IAM principal (for example, your AWS account ID).
To create a new cluster with managed tiered checkpointing, you can pass a parameter using –tiered-storage-config and setting Mode to Enable using an AWS Command Line Interface (AWS CLI) command:
You can also update it using the UpdateCluster API and pass the CachingConfig parameter with the required AllocatedMemory configuration. You can use the CachingConfiguration parameter to define a fixed value or a percentage of the CPU RAM for checkpointing.
Now that your SageMaker HyperPod cluster has the managed tiered checkpointing feature, let’s prepare the training scripts and add them.
Install the managed tiered checkpoint libraries and integrate with your training script
Managed tiered checkpointing integrates with PyTorch DCP. You start by installing the sagemaker-checkpointing library. Then you create and configure a namespace to store the checkpoints based on the defined frequency. Finally, you add the checkpoint function inside your training loop.
To install the library, we simply use Python’s pip. Make sure you already have the dependencies installed: Python 3.10 or higher, PyTorch with DCP support, and the AWS credentials configured properly. To integrate Amazon S3 as another storage layer, you also need s3torchconnector installed.
Now you can import the library on your script and configure the namespace and frequency for checkpointing:
In the preceding code snippet, we have configured managed tiered checkpointing with the same world_size as the number of ranks in our cluster. When you start a distributed training, each GPU in the cluster is assigned a rank number, and the total number of GPUs available is the world_size. We set up Amazon S3 as our backup persistent storage, setting managed tiered checkpointing to store data in Amazon S3 every 100 training steps. Both world_size and namespace are required parameters; the others are optional.
Now that the configuration is ready, let’s set up PyTorch DCP and integrate managed tiered checkpointing.
First, configure the storage writer. This component will pass on to the PyTorch DCP async_save function alongside the model’s state dictionary. We use the SageMakerTieredStorageWriter when writing the checkpoints and the SageMakeTieredStorageReader when restoring from those checkpoints.
Inside your model training loop, you add the storage writer configuration and pass along both the managed tiered checkpointing configuration and the step number:
You can define the step number explicitly for the storage writer, or you can let the storage writer identify the step number from the path where the checkpoint is being saved. If you want to let the storage writer infer the step number from the base path, don’t set the stepparameter and make sure your path contains the step number in it.
Now you can call the PyTorch DCP asynchronous save function and pass along the state dictionary and the storage writer configuration:async_save(state_dict=state_dict, storage_writer=storage_writer)
We have set up managed tiered checkpointing to write checkpoints at our desired frequency and location (in-memory). Let’s use the storage reader to restore those checkpoints. First, pass the managed tiered checkpointing configuration to the SageMakerTieredStorageReader, then call the PyTorch DCP load function, passing the model state dictionary and the storage reader configuration:
To work through a complete example, refer to the following GitHub repository, where we’ve created a simple training script, including the managed tiered checkpointing feature.
Clean up
After you have worked with managed tiered checkpointing, and you want to clean up the environment, simply remove the amzn-sagemaker-checkpointing library by running pip uninstall amzn-sagemaker-checkpointing.
If you installed the solution in a Python virtual environment, then just deleting the virtual environment will suffice.Managed tiered checkpointing is a free feature that doesn’t require additional resources to run. You use your existing SageMaker HyperPod EKS cluster and compute nodes.
Best practices to optimize your checkpoint strategy with managed tiered checkpointing
Managed tiered checkpointing will attempt to write to the in-memory tier first. This optimizes the writing performance because in-memory provides ultra-low latency checkpoint access. You should configure managed tiered checkpointing to write to a second layer, such as Amazon S3, from time to time. For example, configure managed tiered checkpointing to write to the in-memory layer every 10 steps, and configure it to write to Amazon S3 every 100 steps.
If managed tiered checkpointing fails to write to the in-memory layer, and the node experiences an issue, then you still have your checkpoint saved on Amazon S3. While writing to Amazon S3, managed tiered checkpointing uses multiple TCP streams (chunks) to optimize Amazon S3 writes.
In terms of consistency, managed tiered checkpointing uses an all-or-nothing writing strategy. It implements a fallback mechanism that will seamlessly transition between the storage tiers. Checkpoint metadata, such as step number, is stored alongside the data for every tier.
When trying to troubleshoot managed tiered checkpointing, you can check the log written locally to /var/log/sagemaker_checkpointing/{namespace}_checkpointing.log. It publishes data about the training step, rank number, and the operation details. The following is an example output of that file:
Managed tiered checkpointing also writes those metrics to the console, so it’s straightforward to troubleshoot during development. They contain information on which step number is being written to which storage layer and the throughput and total time taken to write the data. With that information, you can monitor and troubleshoot managed tiered checkpointing thoroughly.
When you combine those tools with the SageMaker HyperPod observability stack, you get a complete view of all metrics of your training or inference workload.
Conclusion
The new managed tiered checkpointing feature in SageMaker HyperPod augments FM training efficiency by intelligently distributing checkpoints across multiple storage tiers. This advanced approach places model states in fast access locations such as CPU RAM memory, while using persistent storage such as Amazon S3 for cost-effective, long-term persistence. As of the time of this launch, managed tiered checkpointing is supported only on SageMaker HyperPod on Amazon EKS.
Managed tiered checkpointing delivers fast recovery times without increased storage costs, avoiding complex trade-offs between resiliency, training efficiency, and storage costs. It has been validated on large distributed training clusters that range from hundreds of GPU to more than 15,000 GPU, with checkpoints being saved within seconds.
Integrating managed tiered checkpointing on your training scripts is straightforward, with just a few lines of code, providing immediate access to sophisticated checkpoint management without requiring deep engineering expertise.
For more information on how managed tiered checkpointing works, how to set it up, and other details, refer to HyperPod managed tier checkpointing.
